Processorfabrikant:
Intel
Processor socket:
LGA 1851 (Socket V1)
Compatibele processors:
Intel Core Ultra (Series 2)
Supported processor sockets:
LGA 1851
Maximaal intern geheugen ondersteund door processor:
256
Ondersteunde geheugen types:
DDR5-SDRAM
Aantal geheugenslots:
4
Maximum intern geheugen:
256
Geheugen slots type:
DIMM
Geheugen kanaal:
Dual-channel
ECC-compatibiliteit:
non-ECC
Supported memory clock speeds:
6400,9200
Ondersteunde geheugenkloksnelheid (max):
9200
Ondersteunde opslagstationinterfaces:
M.2,SATA III
Ondersteunde types opslag-drives:
HDD & SSD
Maximum aantal HDD's per behuizing:
8
Aantal storage drives ondersteund:
4
RAID support:
Y
Soorten RAID:
0,1,5,10
Ingebouwde grafische adapter:
N
USB 2.0 aansluitingen:
4
USB 3.2 Gen 1 (3.1 Gen 1)-aansluitingen:
4
USB 3.2-connectoren (3.1 Gen 2):
1
Aantal SATA III connectors:
4
Aantal SATA II connectors:
0
Aantal SATA-aansluitingen:
0
Totaal aantal SATA-connectoren:
4
ATX Power connector (24-pin):
Y
Aansluiting voor CPU koeler:
Y
EPS power connector (8-pin):
Y
Aantal EPS-voedingsaansluitingen (8-pins):
1
TPM connector:
Y
Aantal USB 2.0-poorten:
4
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A:
2
Aantal poortenUSB 3.2 Gen 1 (3.1 Gen 1) Type C:
1
Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type A:
0
Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type C:
1
Aantal Ethernet LAN (RJ-45)-poorten:
1
VGA (D-Sub)poort(en):
0
Aantal HDMI-poorten:
1
HDMI versie:
2.1
Aantal DisplayPorts:
1
DisplayPort versie:
1.4
Hoeveelheid Thunderbolt ports:
1
Wifi:
Y
Ethernet LAN:
Y
Ethernet interface type:
5 Gigabit Ethernet
Wifi-standaard:
Wi-Fi 7 (802.11be)
Wi-Fi-standaarden:
802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac),Wi-Fi 6 (802.11ax),Wi-Fi 6E (802.11ax),Wi-Fi 7 (802.11be)
Bluetooth:
Y
Bluetooth-versie:
5.4
Component voor:
PC
Moederbord form factor:
ATX
Moederbord chipset familie:
Intel
Chipset moederbord:
Intel Z890
Audio-uitgangskanalen:
7.1
Audiochip:
Realtek ALC897
Kleur van het product:
Black
Ondersteunt Windows:
Windows 11
PCI Express x1 (Gen 4.x) sleuven:
1
PCI Express x4 (Gen 4.x) sleuven:
2
PCI Express x16 (Gen 5.x) sleuven:
1
Aantal M.2 (M) slots:
4
Breedte:
243.84
Diepte:
304.8
mSATA ports hoeveelheid:
0
