Processorfabrikant:
Intel
Processor socket:
LGA 1700
Compatibele processors:
Intel Celeron,Intel Pentium,Intel Pentium Gold
Supported processor sockets:
LGA 1700
Ondersteunde geheugen types:
DDR5-SDRAM
Aantal geheugenslots:
4
Maximum intern geheugen:
128
Geheugen kanaal:
Dual-channel
ECC-compatibiliteit:
non-ECC
Supported memory clock speeds:
4800,5000,5200,5400,5600,5800,6000,6200,6400,6600,6800,7000
Ondersteunde geheugenkloksnelheid (max):
7200
Niet gebufferd geheugen:
Y
Ondersteunde opslagstationinterfaces:
M.2,PCI Express
Ondersteunde types opslag-drives:
HDD & SSD
Aantal storage drives ondersteund:
10
RAID support:
Y
Soorten RAID:
0,1,5,10
Ingebouwde grafische adapter:
N
USB 2.0 aansluitingen:
4
USB 3.2 Gen 1 (3.1 Gen 1)-aansluitingen:
2
USB 3.2-connectoren (3.1 Gen 2):
1
Aantal SATA III connectors:
6
Aantal SATA II connectors:
0
Aantal SATA-aansluitingen:
0
Aansluiting voor audiopaneel aan voorzijde:
Y
Voorpaneel-connector:
Y
Aansluiting voor CPU koeler:
Y
Chassis intrusion aansluiting:
Y
TPM connector:
Y
RGB LED-aansluitrail:
Y
Aantal USB 2.0-poorten:
2
Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A:
2
Aantal poortenUSB 3.2 Gen 1 (3.1 Gen 1) Type C:
0
Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type A:
3
Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type C:
0
Aantal Ethernet LAN (RJ-45)-poorten:
1
VGA (D-Sub)poort(en):
0
Aantal HDMI-poorten:
1
DVI-D poorten:
0
Aantal USB 3.2 Gen 2.2 Type-C-poorten:
1
Aantal DisplayPorts:
1
S/PDIF-uitgang:
Y
Wifi:
Y
Ethernet LAN:
Y
Ethernet interface type:
2.5 Gigabit Ethernet
Wifi-standaard:
Wi-Fi 6 (802.11ax)
Wi-Fi-standaarden:
802.11a,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac),Wi-Fi 6 (802.11ax)
Bluetooth:
Y
Bluetooth-versie:
5.3
Component voor:
PC
Moederbord form factor:
ATX
Moederbord chipset familie:
Intel
Chipset moederbord:
Intel Z790
Audio-uitgangskanalen:
7.1
Kleur van het product:
Aluminium,Black
Ondersteunt Windows:
Windows 10 x64,Windows 11 x64
PCI Express x1 slots:
1
PCI Express x16 slots:
3
Aantal M.2 (M) slots:
4
BIOS type:
UEFI AMI
Grootte BIOS-geheugen:
256
Versie Desktop Management Interface (DMI):
6.4
Systeem Management BIOS (SMBIOS) versie:
3.5
Breedte:
304.8
Diepte:
243.84
Meegeleverde kabels:
SATA
mSATA ports hoeveelheid:
0
